How to use USB-C to HDMI Cable
If you feel like you need a bigger screen to watch movies or set up dual monitors for your work, what you need to do is source out your content to another bigger, better screen.
You have USB-C connectors in your mobiles, tablets, and some laptops. For monitors and TV screens, you have HDMI connectors. To allow streaming directly from your mobile to your TV screen, you would require a USB-C to HDMI cable.
You don’t even require an HDMI adapter in between, how cool is that!
But what are the exact requirements and exactly how to use USB-C to HDMI, let’s find out.
How to use USB-C to HDMI Cable?
Using a USB-C to HDMI cable is quite simple. You just need to follow a few steps.
- Connect the USB-C plug into your USB-C device
Connect the USB-C plug into your tablet, laptop or mobile.
*Make sure your host device provide video out, which means the USB-C port must supply DP alt Mode!
- Connect the HDMI end to the display
Connect the HDMI plug to the monitor or screen you want to display the video.
- Turn on the TV or monitor and select the correct input source.
- Done. Your device's screen should now be displayed on the TV or monitor.
Note: Make sure that your device supports HDMI video output and that it has the necessary drivers installed. Also, ensure that your TV or monitor supports the resolution and refresh rate of your device. If you encounter any issues, consult the user manual or technical support for your device and TV or monitor.
And you are good to go.
Enjoy your content on multiple screens. You don't need any additional software.
-
Or if you want to set up Dual Monitors for Laptop, check this out.
Or check this page to see why you can't connect successfully.
Or you wanna know How to Connect MacBook to Monitor Closed / Clamshell Mode?
Click ⬇️ to view the full video.
An important thing to understand is that not all devices with a USB type C port can stream data through a USB-C to HDMI cable. USB has different standards namely 3.0, 2.0, etc.
These differ in terms of data transfer speed.
A USB type C port may support any of these standards but to provide output for an HDMI port, your device needs to have a USB-C 3.1 port or a thunderbolt 3 port, which supports DP Alt mode.
USB-C 3.1 would either mean USB-3.1 Gen 1 (also called USB-C 3.0) or the USB-C 3.1 Gen 2.
If you are thinking about what a thunderbolt port is; by looks, a thunderbolt port is the same as that of a USB-C port but the difference lies in the speed. Thunderbolt 3 gives a maximum data transfer speed of 40 Gbps which is four times that of USB-C 3.1.
This was a video and data transfer protocol developed by Intel, but plug-in perspective remains the same as a USB-C. Thunderbolt port would have a lightning bolt-shaped label beside it.
Source: unsplash
Considerations when buying USB-C to HDMI Cable
- Reliability
A reliable cable is the one that gives better durability.
For instance, firm connections on plug and unplug will decrease cable vulnerability.
On the build side, the aluminum case makes for a more robust connector, helps in heat dissipation, and also minimizes interference for stable WiFi.
Another important factor is nylon shielding which is effective in avoiding damage in the long run.
- Cable Length
An option to choose the cable length as per the need is also what people look for.
How to use USB-C to HDMI setup depends on whether you need a small length cable or a large one.
UNI gives the option to choose between 3ft, 6ft, 10ft, and 15ftcable length, so you can set up your system in an elegant manner.
- Compatibility
Before you buy your USB-C to HDMI cable, you need to make sure that it is compatible with your device.
You also need to keep in mind that your device’s USB-C port supports DP Alt Mode.
DisplayPort Alternate Mode is a functional extension of the USB-C port that enables it to directly connect to another display.
While we have seen how to connect USB-C to HDMI and what are the specifications needed, let’s have a look at Why UNI USB-C to HDMI cable is the best choice available out there.
- To begin with, it provides a high resolution of 4K@60Hz and is also backward compatible with 4K@30Hz, 1080p.
- It supports HDMI 2.0 and is HDCP 2.2 Compatible, giving ultra-high performance.
- It has a braided nylon cable, advanced aluminum case and an option for a lifetime warranty, making it an ideal choice.
- It comes in variable lengths, so you can select the one as per your need. It is compatible with a variety of devices.
